Selecting the right conveying system for a dust collection application depends on several factors, including the type of material being conveyed, the required transfer distance, the volume of dust, and the system’s operating conditions.
For fine, lightweight dust over long distances, a pneumatic conveying system—either dilute or dense phase—may be ideal, as it efficiently transports dust through pipes using air pressure or vacuum. If the dust is heavier, abrasive, or collected in large volumes, a mechanical conveyor like a screw conveyor might be more suitable, as these systems provide controlled material flow with minimal wear.
Evaluating factors like dust characteristics, energy efficiency, and maintenance requirements will help determine the most effective conveying solution for your specific application. Here we cover the two main types of conveying systems.
You need a conveying system whenever you need to transport bulk materials from point A to point B within your facility
What Is Pneumatic Conveying?
Pneumatic conveying is a method of transporting bulk materials through a pipeline using a stream of air or another gas. This system is widely used in industries such as food processing, pharmaceuticals, chemical manufacturing, and dust collection. The materials, often in powder or granular form, are moved from one point to another by controlling the velocity and pressure of the conveying air. This system is particularly effective for handling dry materials in a closed environment, minimizing contamination and product loss.
How Does a Pneumatic Conveying System Work?
- Air Supply: A blower or compressor generates the required airflow.
- Feed System: Material is introduced into the airstream through a feeder, such as a rotary valve or venturi system.
- Conveying Pipeline: The material is transported through pipes, either in a dilute or dense phase manner.
- Separation System: At the destination, a separator (such as a cyclone collector or baghouse filter) removes the transported material from the air stream.
- Discharge System: The material is collected in bins, silos, or another storage unit for further processing or packaging.
A pneumatic conveying system can transport materials over long distances, around obstacles, and through complex facility layouts.
In a dense phase pneumatic system, the blower or fan is placed after the dust collector, creating negative pressure and making it ideal to transport fragile or abrasive materials that need gentle handling.
In a dilute phase pneumatic system, the fan pushes the air (positive pressure) suspending materials in the air stream. It is commonly used for lightweight and non-abrasive materials.
What Are the Different Types of Pneumatic Conveyors?
- Dense Phase Conveying: This method moves materials at a low velocity with a high-pressure system, making it ideal for fragile or abrasive materials that need gentle handling. It reduces wear and tear on the system and minimizes material degradation.
- Dilute Phase Conveying: This system operates at high velocity and low pressure, suspending materials in the air stream. It is commonly used for lightweight and non-abrasive materials and is more cost-effective for certain applications.
What Are the Advantages of Pneumatic Conveying?
Pneumatic conveying offers several advantages over traditional mechanical conveying systems, including:
- Flexibility: The system can transport materials over long distances, around obstacles, and through complex facility layouts.
- Hygiene and Safety: The enclosed system prevents contamination, making it ideal for industries that require high sanitary standards.
- Minimal Maintenance: With fewer moving parts than mechanical conveyors, maintenance requirements and downtime are reduced.
- Automated Control: Many pneumatic systems are easily integrated into automated production lines, improving process efficiency.
What Is Mechanical Conveying?
Mechanical conveying refers to the use of physical components, such as belts, screws, or chains, to transport bulk materials, including dust, powders, and granules, from one point to another. Unlike pneumatic systems that rely on airflow, mechanical conveyors move materials using rotating or moving mechanical parts. These systems are widely used in industrial dust collection applications, ensuring efficient material handling.
How Does a Mechanical Conveying System Work?
A mechanical conveying system operates by continuously or intermittently moving collected dust or bulk material through a controlled pathway. The system consists of a motor-driven mechanism—such as a screw, belt, or chain—that transports material along a designated route. The movement can be horizontal, inclined, or vertical, depending on the application’s requirements. Mechanical conveyors are often integrated with dust collection systems to transfer captured particulates from hoppers or collection bins to disposal or storage areas.
Belt conveyors consist of a continuous looped belt that moves over rollers or pulleys to transport materials.
What Are the Different Types of Mechanical Conveyors?
1. Screw Conveyors
Screw conveyors use a rotating screw blade (also called an auger) inside a trough or tube to move material forward. They are ideal for transporting bulk powders, granules, or semi-solid materials over short to medium distances. Screw conveyors are widely used in dust collection systems to transfer collected dust from hoppers to disposal or storage areas.
2. Conveyor Belt
Belt conveyors consist of a continuous looped belt that moves over rollers or pulleys to transport materials. They are best suited for moving large volumes of material over long distances and can be used in both horizontal and inclined applications. Belt conveyors are commonly found in industrial facilities handling bulk materials such as sand, gravel, or collected dust.
Do you need help choosing, designing and installing a conveying system? Baghouse.com can help you! Call us now or email us at info@baghouse.com
